Description
The Mitsubishi Electric MFZ-KT50VG Floor mounted air conditioning system is a well designed and extremely versatile floor mounted system. This air conditioning systems auto swing three vanes provide natural and comfortable cooling throughout the room, and provides optimum air distribution . There is an inbuilt 7-day timer to aid control and save energy.
Indoor Model No | MFZ-KT50VG |
Cooling Capacity (Nominal) | 5.0 (1.2 – 5.6) |
Heating Capacity (Nominal) | 6.0 (1.5 – 7.2) |
SHF (Nominal) | 0.72 |
COP / EER (Nominal) | 3.23 / 3.23 |
SCOP / SEER (BS EN14825) | 4.2 / 6.8 |
ErP Energy Efficiency Class (Heating / Cooling) | A+ / A++ |
Airflow (l/s) Heating – Silent – Lo – Mi – Hi – SHi | 100-128-57-193-233 |
Airflow (l/s) Cooling – Silent – Lo – Mi – Hi – SHi | 93-112-143-173-205 |
Pipe Size mm (in) | 12.7 (1/2″) / 6.35 (1/4″) |
Sound Pressure Level (dBa) Heating/Cooling – Silent – Lo – Mi – Hi – SHi | 29-35-40-44-49 / 28-32-37-42-48 |
Sound Power Level (dBa) | 60 |
Dimensions (mm) Width x Depth x Height | 750 x 215 x 600 |
Weight (kg) | 15 |
Electrical Supply | Fed by the Outdoor Unit |
Fuse Rating (BS88) – HRC (A) | 6 |
Interconnecting Cables No. Cores | 4 |
Outdoor Unit Model No | SUZ-M50VAR2 |
Sound Pressure Level (dBa) Heating/Cooling | 49 / 48 |
Sound Power Level (dBa) Cooling | 64 |
Weight (kg) | 41 |
Dimensions (mm) Width x Depth x Height | 800 x 285 x 714 |
Electrical Supply | 220 -240V , 50Hz |
Phase | Single |
System Power Input (kW) Heating/Cooling (Nominal) | 1.61 / 1.54 |
System Power Input (kW) Heating/Cooling (UK) | 1.37 / 1.32 |
Starting Current (A) | 8.0 |
System Running Current (A) Heating/Cooling (MAX) | 8.0 / 7.1 (13.5) |
Fuse Rating (BS88) – HRC (A) | 20 |
Mains Cable No. Core | 3 |
Max Pipe Length (m) | 30 |
Max Height Difference (m) | 30 |
Charge Refrigerant (KG) / CO2 Equivalent (T) – R32 (GWP 675) – 7M | 1.20 / 0.81 |
Max Additional Refrigerant (KG) / CO2 Equivalent (T) – R32 (GWP – 675) | 0.46 / 0.31 |
